Restoring Data RAID arrays simple methods
Introduction
In this article written about data recovery from RAID arrays in simple cases. We use methods that can be learned without having expertise in this area, and for a short time. Cases that can be attributed to the complex, too different from each other, and require an individual approach, so it makes no sense to describe them in one article. However, you can discuss the specific situation in a dedicated section of the forum.
Of course, if the lost information is crucial, and you are not a specialist in media and data recovery, it is highly recommended to go directly to the company, whose main field of activity is the solution of such problems. But if the opportunity is more likely to get back valuable information pales before their own desire to try to restore the data, then this article is for you.
The reasons for withdrawal RAID arrays fail
The most common cause of failure of disk arrays is the negligence system administrators who are counting on that “one bomb crater twice does not fall. During the work, such as RAID 5, the failure of one of the disks. Array continues to operate more correctly, but with a noticeable decrease in speed. System Administrator, noting the failure of the drive, not in a hurry to take action, because expects that the array in a form more able to spend some quality time. It is at times misleading.
If you break down one of the drives, it is best to immediately back up critical data, and then replacing one of the drives, make rebild array.
Why do have to note that you must first make a backup? Because when you try rebilda array, sometimes happens is that the process hangs. Typically, this happens if in the process of reading \ writing on one of the disks found bad-block, and the controller can not deduct information from the sector. As a result, after a long and useless waiting, server overload. After that, it turns out that the array is fully collapsed. Stuck in such cases is likely due to incorrect processing of the exception. Typically, this phenomenon is more prevalent in low-cost models of controllers, but also occurs when using expensive hardware.
To avoid such a situation can also recommend to rebildom test drives on the bad-blocks.
Another common reason for denial of an array is the simultaneous transfer of multiple disk mode off-line. Practice shows that most often occurs because of problems with SMART, or the accumulation of bad-blocks. While their number does not exceed a certain value, the disk is working properly, but one day, the array no longer starts. And like all good, and the media, judging by the sound, normally starts, and the controller correctly determined, but there just do not understand why the status of a disk off-line, the array does not start and the data does not give. All due to the fact that the controller when you try to take the necessary data from the disk can not count them, or diagnosing SMART, identifies the disk as “dead”.
One can cite many examples of failures in the array, but what if it happened yet? Information is lost, it must be restored.
A small digression
Available now, you can see lot of different equipment, which can be used to create arrays, at prices ranging from 20 to several thousand dollars. Comparison of reliability – a complex question, but guess what the price difference is “not a finger sucked”, I think everyone can.
First and foremost I would like to pay special attention to the fact that the preservation of data using RAID arrays is not a panacea. When using arrays without performing timely backups, data loss can occur, the question is, what these losses can be caused, and what is the probability of their occurrence. Practice shows that occur as a malfunction of the controller, as well as failures in the hard disk, or is one from another.
Controllers budget level, naturally less reliable, as they have a simplified algorithm works and disaster recovery, resulting in a greater probability of losing information. Dear model, though also not perfect, much more reliable, including from the fact that algorithms for error handling them more perfect. Matters relating to features of certain models RAID controllers, you can ask here.
In any case, relying on the reliability of the arrays and not taking care of the timely backups, you risk one day stay without “safely stored” information. The probability of data loss can be significantly reduced by regularly monitoring the state of the array and performing maintenance work, but completely nullify the way it can.
Theory: RAID Levels and principles of recovery
Most now use arrays of levels 0, 1, 10, 5, 50. Recently there has been increasing interest in the sixth level.
Below is a summary of the principles of the arrays. More information about this, please read the relevant article.
RAID 0 – use of alternating records (stripe). Constructed from two or more drives. Information is recorded on all drives in the array definition block (8Kb, 16Kb, 32Kb, 64 Kb, 128Kb …) size. Files whose size is one block, uniformly “scattered” on two or more disks included in the array.
Due to the lack of redundancy or duplication of data, at a failure of one drive, restore the information in full, without the use of data from a failed drive is not possible. Exceptions will only files smaller than block size. For a full recovery in these cases, you must first remove the data from a failed disk, then restore the RAID.
In cases where the disks are in good working order, and the array refuses to work correctly, the restoration is produced programming methods, which are described below.
RAID 1 – mirroring the use of technology (mirror). Constructed from two disks. Information on them is identical. In the event of failure of one drive array will remain operational.
If there is a malfunction of the controller and an array ceases to be determined, then the data recovery can be performed using the tips from the article “A simple data recovery. To do this, one of the drives to be connected to the computer directly, bypassing the RAID controller. If you are lucky, after you connect your data may be accessible without the use of the programs described in the above article.
RAID 10 – is an association of level 0 to level 1, ie Two stripe together in a mirror. In an array using at least 4 disks. He can remain operational in case of breakdown of one of its constituent RAID 0.
If you have any problems, you must first decide what exactly has a problem – with the controller or disk.
When the problem at the controller level, you should determine which hard drives are the pairs that make up the stripe. It is important not to confuse the disk, because this will lead to lost time and lack of results. Once it becomes known, takes one such couple, and it removed the information in the same manner as with independent RAID 0.
During operation, RAID 10, it does happen that fail two disks. Here, the following options:
1) Both the disk belong to the same stripe, the controller will correctly handle the exceptional situation, and the array continues to function normally.
2) Both disks belong to the same stripe, but the array is falling apart. In this case, simply take the defective stripe, and software collect it (more on that below).
3) Disks belong to different stripe, but one of them survived the first, and in another second drive. Try the software to collect from them RAID 0.
4) out of order with the same name disks of different stripe. Alas: (One of the failed disk will repair, or any another way to open its data. Then, a software build.
RAID 5 – arrays with parity. Their chief advantage is that they block the distribution of information and control blocks of parity across all disks in the array. To create such an array requires a minimum of three disks. The volume of the array is equal to the sum of volumes of its constituent drives minus one drive. Power parity is used to calculate the missing information at a failure of one of the drives that make up the array. Thus, the loss of one drive and data is lost, and the array can continue to work.
Unfortunately, the condition is that after the failure of one drive, the controller does not correctly handle an exceptional situation and an array ceases to work properly or fully “drops”. Such failure may also arise during executed after replacing the disk rebilda. Sometimes, such that within a short time after the death of the first disk fails another.
If the array has collapsed, and the number of faulty disks no more than one, then it is possible to collect the software, just as going RAID 0. Failure of the two drives will first need to recover, or remove information on the defective drive with one of them, and only then you can do assemble the array.
Practice: Description of the action in the fall of the array
I’ll tell you about what you should not do, in order to finally lose data.
First of all, do not create a new array of old CDs in the hope that it will run and will operate as before. This may work, but rather high probability that the controller will be implemented actions that will lead to an irreversible loss of data.
Starting the initialization is also nothing good will not, so it is recommended to reject it, and if it is not possible, then use only the quick init.
What else can hurt an array? Launch chekdiska or something like that. But in general it is best to remember that the loss of information on RAID should reject any entry on the disks. If you are unsure whether certain actions will lead to a loss of information or not, it is best to either consult with someone who knows it, or refuse to comply.
Methods and algorithms for RAID recovery
Software RAID reconstruction for example arrays 0 and 5 levels
The main way to recover data from RAID is a software build an image of the array. Ie using software components from different disks are arranged in the correct sequence. The order of blocks in the array depends on the location of disks on the channels and the algorithm of the controller.
Before the work is to create clones of all disks in order to protect themselves from wrong actions. Copies can be made both in the form of files or directly to other drives. Work with copies or originals – you decide. I strongly recommend that you use in the copy, because For example, if the source media in some sectors were bad-blocks, then work with these disks can significantly worsen their condition.
If you know the parameters with which to create an array, then it will accelerate the build process. When the known size of the block and the sequence of titles, the selection of these parameters, knowledge of which is necessary for correct assembly of the array, you do not need. But if they still remain unknown, the work will be more.
There are automated tools to search configuration and recovery RAID, for example, such as software RAID Reconstructor. If you put in it the level of the array, it will try to find the original sequence of disk block size, and suggest an algorithm to write information to disk.
Next I will describe step by step action when using this utility.
So, here we face a window running the program:
The first step required to get started – is the choice of type array, which you need. The choice is made in the window «RAID TYPE».
By specifying the type of the array for the assembly you must specify the number of disks in the box «# drives». After you specify the required number of titles below will flash white a few fields (their number will equal the number of values you drive). Brings to each of the illuminated windows, we click the right mouse button and select the disks that there is a weight. Once the drive is selected – go to the item «Block size».
Here you must specify the block size, if known, if not, leave the item unchanged and boldly press on «Open drives» and then immediately on the button «Analyze».
Before you appears a new window. In the case of RAID 0 is:
And in the case of a RAID 5 there is:
So, in front of us is a window that will ask your search drive sequence, the size of the block, and if we collect RAID 5, parity rotations.
Having information about what the controller was to create an array which was used by the algorithm to write information to disk, as well as knowledge of the block size, will help save time. To do this, you want to exclude unnecessary parameters in the windows «Block size» and «Parity rotations». But if you do these parameters do not know, it’s best to leave everything unchanged and click «Next», thus providing a tool to sort out themselves.
Once you click, the program will calculate all possible options and will try to give you the most faithful, though in cases where the destruction of the array are quite strong, the result may not be entirely accurate. If after reenactors spent analysis, the bottom appeared the inscription «Recommendation: choose entry 1″, you can breathe easy. The correct algorithm is found.
Further options may be few. Either rewrite the image of the array to the file or save it to disk or array, or create a virtual image and continue the analysis of utility Captain Nemo, Get Data Back or DiscEditor. What exactly is done – you decide.
Even as an option, using the knowledge about the location of disks, the algorithm records and block size, you can restore the RAID, using a program called UFS Explorer. Guidelines for use of this product can be found in the documentation.
When an array is built correctly, and file systems on it have no logical damage, you can get access to the data by standard methods. In particular, if the image is copied onto the hard disk will be enough to connect it to your computer and restart the OS (if you do not support hot insertion).
I remind you that the above method can recover RAID only in the most simple cases. Description of complex situations is beyond the scope of this article, and does not imply the use of lay persons. For example, you may not be able to restore the RAID method described in the case when the controller writes the start of the disk configuration information. Do not tell the program the number of sectors occupied by official data, you can get an incorrect result of automatic selection of the configuration of the array. These configuration blocks are unique to each model, controller, and know exactly their size can only examine the contents of the primary sectors.
Hardware RAID reconstruction
An alternative to creating the image may be a hardware assembly. I must say that without knowing the algorithm of the controller, or without a backup absolutely all disk array, use this “shamanic method” is strictly not recommended, because You can make these changes to disk, resulting in you no longer get the data, even turning to specialists. This information is given for educational purposes rather than as a guide to action.
So, the method is that the array is recreated on the controller again, with all similar previous configuration settings. Please note that if you create will be launched rebild, the chances that your data will survive a little. Some models of controllers after a new array automatically perform initialization, which can also lead to irreversible loss of data.
If all drives in the array was undamaged, it is likely that without any further action you will again have access to information. It is also possible that it will take to work with tools such as R-Studio, Get Data Back or something similar.
In the cases of Reid fifth level, when one of the disks fails, you can create an array with the replacement drive for the same defective. When an array is created (rebild not to!), After the operating system, this disc will need to disable “in hot”. As a result, again, you can get access to their data directly, or through the use of programs for the logical reconstruction of information.
